9 kW 2-level boost converter for solar photovoltaic solutions

Infineon’s 9 kW dual channel boost converter reference design helps simplify the process of building and operating 2-channel boost converters for solar photovoltaic applications and beyond.

The modular design allows for a more compact and cost-effective solution, featuring all necessary traces for a third channel, as well as connectors for integrating custom passive components.

With the additional control board, which features signal conditioning circuits, power conversion software and a graphical user interface (GUI) the REF_9KW2LBOOST reference design serves as a blue print for reducing time-to-market of your next photovoltaic design!

Key features

• Isolated gate driver card
• Current sensors for each DC input
• Large heat sink for passive cooling
• Fans for high power rating
• Built-in auxiliary power supply
• Control card with GUI
